Description
- Brushless Advantage: fewer moving parts means less wear and longer life
- Equipped with Remote Sense which can reduce battery charge time by 50% Remote Sense utilizes a second wire that reads the actual voltage at the battery. This signals the alternator to boost its output to compensate for the voltage drop, ensuring 14 Volts at the battery. The proper voltage forces more current into the battery bringing it to a full state of charge between vehicle stops.
- OE approved, assuring OE quality and performance for aftermarket replacements
- Superior output producing up to 170 Amps at road speed and 100 Amps at idle
Technical Information:
- Model: 40SI
- Mount Type: Pad
- System Voltage: 12V
- Rated Output: 240 Amps
- B+ Output Terminal: 5/16
- R Terminal: #10
- I Terminal: #10
- Remote Sense Terminal: Yes
- Ground Terminal: Negative
Product Parts:
- Fan – 10520330
- DE Frame w/ Bearing – 10514417
- Ball Bearing Assembly – 10528573
- Rotor Kit – 10528574
- RE Cover – 10528575
- Stator Arm – 10517486
- Regulator – 10529295
- Hardware Repair Kit – 10528570
- RE Rotor Bearing – 10520737
Cross References: BLP2332GH, BLP2334GH, A0014940PA, 4940PA, A0014948PA, 4948PA, A00149551PGH, 4951PGH, A0014958PA, 4958PA, A0014959PA, 4959PA
