Description
- Dual internal fan (DIF) design provides maximum cooling technology
- OE approved, assuring OE quality, reliability and performance for aftermarket replacements
- Superior output producing up to 200 Amps at road speed and 140 Amps at idle
- Equipped with Remote Sense which utilizes a second wire that reads the actual voltage at the battery. This signals the alternator to boost its output to compensate for the voltage drop, ensuring 14 Volts at the battery. The proper voltage forces more current into the battery bringing it to a full state of charge between vehicle stops. Reduces battery charge time by 50%.
Technical Information:
- Model: 28SI
- Mount Type: J180 Hinge
- System Voltage: 12V
- Rated Output: 200 Amps
- B+ Output Terminal: 5/16
- R Terminal: #10
- I Terminal: #10
- Remote Sense Terminal: Yes
- Ground Terminal: Negative
Product Parts:
- DE Frame w/ Bearing – 10524420
- Stator Assembly – 10519471
- Rotor Assembly – 10514735
- RE Frame – 10521072
- Brush Holder Assembly – 10521657
- Rectifier Bridge – 10519680
- Regulator – 10527709
- Ball Bearing Assembly – 10519853
- RE Rotor Bearing – 10451619
- RE Cover – 10520461
- Negative Diode – 10511571
- Hardware Repair Kit – 10528475
Cross References: 8600307, 8700083, 61009625, 8600390, 2331GH, 2333GH, 4836AAH, 4836LGH, 4846AAH, 4850AA, 4860AA, 4860JB, 4861JB, 4863JB, 4868JGH, 4884JB, A0014836AAH, A0014836LGH, A0014846AAH, A0014850AA, A0014860AA, A0014860JB, A0014863JB, A0014868JGH, A0014884JB, BLD2333GH, BLD2331GH
