Description
Gates® GlobalSpiral™ couplings provide superior performance for extremely high-pressure, high-impulse spiral-wire hydraulic hose applications. The innovative two-piece, no-skive design allows for fast, tailor made assemblies. Eliminating the skiving process drastically reduces assembly time, labor, odor, fabrication errors and contamination of the fluid power system. Maximum application coverage – GlobalSpiral™ couplings are available in more than 80 thread configurations, so finding the right fit for your assembly has never been easier. GlobalSpiral™ thread ends are able to handle working pressures up to 6,000 psi. Coated with TuffCoat® plating – more than five times better corrosion resistance than SAE ASTMB117 specification.
- Unique bite-the-wire crimp design allows for improved coupling retention and blow-off prevention.
- Reduces parts inventory by 30% since only one stem is required for all spiral-wire hose types.
- Surpasses one million impulse cycles.
Product Specifications
- Inside Diameter (in): 1
- Inside Diameter (mm): 25.4
- Thread Size: 1-11 1/2
- H1 Stem Hex (in): 1 3/8
- C Cutoff (in): 1.94
- C Cutoff (mm): 49.3
- L Length (in): 4.17
- L Length (mm): 105.9
- C (in): 1.94
