Description
- ULTRA FLASH II
- Solid-state electronics are sealed in polyurethane for moisture and corrosion protection
- Surface mounts with two 1/2″-6 pan head screws at 212″ centers or with two 4″ cable ties (both included)
- Protects against short circuit overloads with a self-resetting feature
- Works with LED or incandescent lamps on 12V or 24V electrical systems
- 97231, 97232 and 97233 rated for loads below 25 amps or 12,-32 cp bulbs
- 97201 rated for loads below 17 amps per channel or 8-32/3 cp bulbs
- Optional remote wiring requires 12″ jumper wire, 94954
- 97231, 97232 and 97333 feature folding bi-polar plug with 11″ leads for reverse polarity operation
- 97201 features three 1/4″ tabs and one 1/4″ ring with heat shrink tubing and 12″ leads
- 97201 used for wig/wag system
- For interior/cab use only
- Do not expose to moisture or liquid
Technical Data:
- Category: Flasher Module
- Flasher Ampere Capacity: FMVSS 108|SAE
- Housing Material: Aluminum
- Kit: No
- Lamp Connection: Hardwired
- Mount Type: 2 Screw
- Number of Wires: 4
- Plug Side One: Hardwired
- Plug Side Two: Spade Terminal|Ring Terminal
- Voltage: 12/24V
