Description
- 3030 LifeSeal+
- Stroke 2.5″
- Pushrod 10.00″
- Heavy duty housing
- Standard power spring
- Threaded with clevis
Product Specifications
- Actuator Type Size: 3030
- Stroke Type: Long
- Available Stroke: 3.0″
- Pushrod Threads: 5/8″
- Weight: 23.6 LBS
- A – Length from mounting bracket to end of Spring Housing: 9.72″
- B – Length of Piggyback: 7.19″
- C – Dimension at rolled Spring Housing flange: 8.19″
- D – Dimension at Service Clampband: 10.18″
- E – Stud Spacing: 4.75″
- J – Pushrod Length from face of Service Housing: 10.00″
- K – Distance to Clevis Pin centerline from face of Service Housing: N/A
- S1 – Service Clampband position: 0°
- T – Air Port position: 90°
